FIG 100 Imported Standard Frac Tank Couplings

Part #

4" FTS1

4" FTS2

4" FTS3

4" FTS4

4" FTS5

4" FTS123

4" FTS124

Description - Butt Weld

Male Sub

Wing Nut

Blind (Cap) - External Thread

Female Sub

Cap - Internal thread w/Gasket Only

Male Sub x Wing Nut x Bind (Cap)

Male Sub x Wing Nut x Female Sub

6" FTS1

6" FTS2

6" FTS3

6" FTS3 WBG

6" FTS4-H

6" FTS4

6" FTS5

6" FTS123

6" FTS124

Male Sub

Wing Nut

Blind (Cap) - External Thread

Blind (Cap) w/Buna Gasket

Hose End

Female Sub

Cap - Internal thread w/Gasket Only

Male Sub x Wing Nut x Bind (Cap)

Male Sub x Wing Nut x Female Sub

Part #

Description - Butt Weld

8" FTS1

8" FTS1-OR

8" O'Ring

8" FTS2

8" FTS3

8" FTS3 WBG

8" FTS4-H

8" FTS4

8" FTS5

8" FTS123

8" FTS123-OR

8" FTS124

8" FTS124-OR

Male Sub

Male Sub w/O Ring

O'Ring Buna Gasket

Wing Nut

Blind (Cap)

Blind (Cap) w/Buna Gasket

Hose End

Female Sub

Cap - Internal thread w/Gasket

Male Sub x Wing Nut x Bind (Cap)

O'Ring Male Sub x Wing Nut x Hose End

Male Sub x Wing Nut x Hose End

O'Ring Male Sub x Wing Nut x Hose End
